SMC Water Tank For Sale

Product Introduction

SMC molded FRP water tank is worldwide adopted as a new type of water tank assembled from integral high-quality SMC molded FRP plates. It can be assembled into a water tank with a volume of 0.125-1500 cubic meters according to customers’ needs. It is characterized by using food-grade resin and adopting the manufacturing method of mechanical compression molding, so it has the advantages of cleanliness and non-pollution, high strength, light weight, corrosion resistance, beautiful appearance, long service life, and convenient installation and maintenance.

The central depression of each water tank plate improves the pressure-bearing capacity of the water tank. At the same time, the periphery of each plate has the flanges of 45° and 90° angle. No angle connectors are needed during assembly, which makes it more flexible. The specifications of the water tank plates are: 500mm×500mm; 1000mm×500mm; 1000mm×1000mm; 1500mm×500mm; 1500mm×1000mm; 2000mm×500mm; 2000mm×1000mm. The thicknesses include 4mm, 6mm, 7mm, 8mm, 10mm, 12mm, 14mm, and 16mm, among which the 4mm thick plates are specially used as water tank covers.

SMC molded FRP water tanks are widely used in industrial and mining enterprises, institutions, residences, hotels, restaurants and other buildings as water storage facilities for domestic drinking water, reclaimed water treatment, fire water and other water uses.

Product Details

Product Features

It has the advantages of cleanliness and non-pollution, high strength, light weight, corrosion resistance, beautiful appearance, long service life, and convenient installation and maintenance.

Packing & Shipping

Shunda Group insist on a safe packing concept. The plastic wraps, fillers, cartons are adopted in products packing.  These packing materials can eliminate humidity, shake, extrusion and crash. Our factory has assigned room and professional forklifts for loading to ensure the safety of the products and operators.

Company Profile

Shunda Air Conditioning Equipment Group Co., Ltd. (Shunda for short), founded in 2005 and located in Luquantun Industrial Park, Shandong Province, is a well-known manufacturer in China’s central air conditioning industry. Covering over 70,000 m² with 230 employees, including 27 R&D engineers, Shunda specializes in HVAC systems. It can produce the products including modular air conditioners, fan coil units, ventilators, fans, fire valves, ducts, and more—over 70 types in total. With ISO9001, ISO14001, and ISO18001 certifications, and multiple national honors, Shunda has built a strong reputation under its “Jinxin Shunda” brand. The company has successfully served landmark projects in China and abroad including Southeast Asia and Africa, and continues to uphold a philosophy of innovation, quality and service.

Our Service

Requirement communication and technical consultation

• Shunda Group's professional engineers are available to answer tecnical questions about products.

• Provide customers with documents such as product catalogs, technical manuals, performance parameter tables, installation drawings and operation instructions to ensure that customers well understand the products.

• Tailor customized products and implementation plans for customers according to their specific needs and real working conditions to ensure that the plan has high-cost performance.

Product display and demonstration

• Invite customers to visit the company's factory allowing them to understand the characteristics and advantages of the products in terms of appearance, structure, material, technology.

• Use VR to provide online product display services for customers enabling them to have a comprehensive understanding of the products.

• Provide customers with relative data of the product performance tests conducted by the company in laboratories or actual projects so that customers can understand the actual performance of the products. At the same time, elaborate on the testing methods and standards to ensure the authenticity and reliability of the data.

Installation and commissioning guidance and technical support

• Provide customers with detailed installation guidance including installation instructions, installation drawings, foundation construction needs, and a list of installation tools to ensure the customer's installers can accurately understand and operate.

• Online installation instruction can be provided and the specailized technical engineer can also be dispatched for on-site guidance.

Quality assurance and maintenance

• We provide technical support and spare parts replacement to ensure long-term performance and reliability.

• A 24-hour after-sales service hotline is availbale  to answer customers' repair calls at any time.

Periodic follow-up visits and maintenance services

• During our quality guarantee period, customers will be visited once every three months. After  guarantee period, an online return visit will be conducted once a year to timely collect their opinions and suggestions so as to provide a basis for improving products and services.

• Formulate personalized maintenance schedules for customers according to the usage of products, operation time, and working environment.

Technical training

• Online training courses can be provided regularly for our customers.

• Set up a dedicated technical consultation email and an online customer service platform to reply to customers' questions of our products. For technique questions raised by customers, responses will be given within 24 hours.

FAQ

Q: Are you a  sales agent and manufacturer?

A: We are a manufacturer with a producing zone of 70,000 m². We can produce the host units of central air-conditioning equipment  and its accessories, such as fireproof ducts, louver vents, various valves, fan coil units, air blowers and the like.

Q: Can you accept OEM business?

A: Yes, we can provide customization service. We have our own engineers who can put forward good advices on your drawing.
